IGS-NT Installation Guide
39
HINT
Display is connected via RS-485 only! Use the RS485 socket which is dedicated for
communication with displays.
6.1.4. InteliVision 8
Colour detachable display. Available for all InteliGen, InteliSys and InteliMains controllers.
Connection type: CAN2, RS 485, RS 232.
UNIT
RS232
RS485(2)
DISPLAY –
RS485(1)
CAN2
IG-NT and IM-NT
1
N/A
1
4
IG-NT-BB and IM-NT-BB
1
N/A
2
4
IG-NTC-BB and IM-NTC-
BB
1
1
2
4
IS-NT-BB
1-2*
0*-1
3
4
IS-NTC-BB
1
1
3
4
* Port RS232 and RS485 is shared (so it can be set either to 485(2) or to RS232
