InteliMains
NT
, SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
12.2.4.4 Setpoint: BinInp delay 3
This setpoint adjusts the delay #3 which can be assigned to an input
configured as alarm input (protection).
NOTE:
Protections configured at a binary inputs can have either fixed 0.5s
evaluation delay or there are three independent delay setpoints and one of
them can be assigned to each particular binary input protection.
12.2.4.5 Setpoint: ForceBlockDel1
This setpoint adjusts the delay after the binary input Force block 1 has been
deactivated, when the alarms configured as Force block #1 are started to be
evaluated.
12.2.4.6 Setpoint: ForceBlockDel2
This setpoint adjusts the delay after the binary input Force block 2 has been
deactivated, when the alarms configured as Force block #2 are started to be
evaluated.
12.2.4.7 Setpoint: ForceBlockDel3
