7.9 Values for continuous writing from external sources
This function is especially designed for continuous writing of setpoints from external sources (e.g. via
Modbus connection).
WARNING!
Setpoints must not be written continuously (e.g. via Modbus connection)! If continuous change of
setpoints is required, combination of External values and Force value function needs to be used. The
memory that holds setpoints is designed for up to 10
5
writings. Than memory may be damaged!
It is possible to use up to four different External values for continuous writing from external sources.
The values are adjusted by setpoints in Force value group. Default (also initial) value may be
adjusted, rate of change of ExtValueX (by Binary Inputs EXTVALUEX UP and EXTVALUEX DOWN) can be
adjusted as well as high and low limit of the value.
There are two way, how to adjust External values. One is using Binary Inputs mentioned above.
Second one is to write the value directly using e.g. Modbus. External values then may be converted
using PLC block convert and force into setpoint which is then continuously forced (note: NOT
WRITTEN) by the value of ExtValueX. This way internal memory is safe and no damage may occur.
External values are reverted back to their default (initial) value (given by corresponding setpoint) when
Binary Input for their reset is active (and they change to the previous value after Binary Input
deactivates). When the Binary Input is active the External value cannot be changed by Modbus writing
or by using Binary Inputs for up and down value.
NOTE:
External values are not available for external writing when any Binary Input (up, down or reset) related
to them is active.
Note also that when the controller is reset (powered down and up again), all external values are
reverted back to their default (initial) values.
HINT
For information on how to write (or read) objects from controller via Modbus, please refer to the latest
Communication guide for InteliGen and InteliSys.
7.10 General Purpose Timers
There is 16 general-purpose timers in the controller, each 4 of them are joined together to one output.
That means there are 4 fully independent timer blocks including 4 timer channels each. The combined
outputs from the timer blocks are TIMERACT 1-4, TIMERACT 5-8, TIMERACT 9-12 AND TIMERACT 13-16.
The timers are intended for scheduling of any operations such as e.g. periodic tests of the gen-set,
scheduled transfer of the load to the gen-set prior to an expected disconection of the mains etc. Each
timer channel can be activated only once within a single day. The activation time and duration of each
channel is adjustable (both as hh:mm).
7.10.1 Timer modes
Available modes of each timer:
This is a single shot mode. The timer will be activated only once at preset
date/time for preset duration.
The timer is activated every "x-th" day. The day period "x" is adjustable.
Weekends can be excluded. E.g. the timer can be adjusted to every 2nd day
excluding saturdays and sundays.
The timer is activated every "x-th" week on selected weekdays. The week period
"x" is adjustable. E.g. the timer can be adjusted to every 2nd week on monday
and friday.
