ComAp IGS-NT Series - Page 44

IGS-NT Installation Guide
44
6.1.8.3. Connection to IG-NTC
RS232(1)
RS485(1)
CAN1
Extension
CAN2
Intercontroller
Terminal 1*:
InteliVision 8
Channel 1
InteliVision 8
Channel 2
InteliVision 8
Channel 3
InteliVision 8
Channel 4
InteliVision 8
Communication:
InteliVision 8
RS232(2)
Communication:
InteliVision 8
RS485(2)
Communication:
InteliVision 8
HINT
*Only one external display can be connected to the control unit via RS485(1) – IG-DISP port.
6.1.8.4. Connection to IG-NT-BB
RS485
Display only
CAN1
Extension
modules
CAN2
Intercontroller
and
monitoring
RS232
Terminal 1*:
InteliVision 8
Communication:
InteliVision 8
Channel 1
InteliVision 8
Channel 2
InteliVision 8
Channel 3
InteliVision 8
Channel 4
InteliVision 8
HINT
* Two displays can be connected to the IG-NT-BB control unit via RS485 (display terminal)
with addresses 1 and 2.
