12.2.10 Group: Volt ctrl
12.2.10.1 Setpoint: Voltage gain
This setpoint adjusts the gain factor (P-factor) of the voltage control PI loop.
The integration factor (I-factor) for the voltage control loop is adjusted by the
setpoint Voltage int.
NOTE:
If this setpoint is set to 0 the regulation loop is disabled.
VOLTAGE GAIN AND VOLTAGE INT SETPOINTS ARE ACTIVE DURING:
synchronization between “left” and “right” buses
NOTE:
When this setpoint is set to zero, the corresponding control loop is switched
OFF.
NOTE:
See the chapter Regulation loops overview for general information about
regulation loops and their adjustment.
12.2.10.2 Setpoint: Voltage Int
This setpoint adjusts the relative integration factor (I-factor) of the voltage
control PI loop. The gain factor (P-factor) for the voltage control loop is
adjusted by the setpoint Voltage gain.
