InteliMains
NT
, SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
FUNCTION NAME
(ALPHABETICAL
ORDER)
RELATED SETPOINTS, INPUTS AND
OUTPUTS
RS232 and
RS485
communication
functions
The controller has several settings
regarding RS232 and RS485 functions. It
is possible to set mode of communication
on particular port, speed of
communication and AT commands for
modem connection.
RS232(1) mode
RS232(2) mode
RS232(1)MBCSpd
RS232(2)MBCSpd
RS232(1)MdmIni
RS232(2)MdmIni
RS485(1) conv.
RS485(2) conv.
Up to 16 timers are provided in the
controller (with 4 combined outputs).
They can be used to trigger various
internal functions as well as external
devices. Please refer to a separate
chapter for detailed information.
Timer channel 1
Timer channel 2
Timer channel 3
Timer channel 4
Timer channel 5
Timer channel 6
Timer channel 7
Timer channel 8
Timer channel 9
Timer channel 10
Timer channel 11
Timer channel 12
Timer channel 13
Timer channel 14
Timer channel 15
Timer channel 16
TIMERACT 1-4
TIMERACT 5-8
TIMERACT 9-12
TIMERACT 13-16
TIMERACTIVECOM
TIMER BLOCK 1
TIMER BLOCK 2
TIMER BLOCK 3
TIMER BLOCK 4
TIMER BLOCK 5
TIMER BLOCK 6
TIMER BLOCK 7
TIMER BLOCK 8
TIMER BLOCK 9
TIMER BLOCK 10
TIMER BLOCK 11
TIMER BLOCK 12
TIMER BLOCK 13
TIMER BLOCK 14
TIMER BLOCK 15
TIMER BLOCK 16
It is possible to use up to 8 user buttons.
User buttons can be for example
assigned to software buttons in
InteliVision displays. Pressing of
corresponding button then activates the
output with function that is chosen in the
configuration. For more information on
how to use User Buttons please refer to
a separate chapter.
USER BUTTON 1
USER BUTTON 2
USER BUTTON 3
USER BUTTON 4
User
Configurable
protections
AA
There are several prepared user
configurable protections in default
archive. Please refer to a separate
chapter for complex step-by-step
instructions on user configurable
protections.
Batt >V
Batt <V
Batt volt del
BusL V unbal
BusL Vunb del
BusL I unbal
BusL I unb del
