InteliLite4 AMF20 Global Guide
132
Alarm list
Alarm list is a container of active and inactive alarms. It will appear automatically on the controller display, if a
new alarm occurs, or can be displayed manually from the display menu.
Active alarms are shown as inverted, not yet confirmed alarms are marked with asterisk before them.
Alarm list contains three types of alarms:
Controller built-in alarms
User configured alarms
ECU alarms
Controller built-in alarms
An alarm message in the Alarm list begins with a prefix, which represents the alarm type (e.g. Wrn, Sd, BOC).
Then the alarm name follows. In some cases the prefix can be omitted.
User configured alarms
An alarm message in the Alarm list begins with a prefix, which represents the alarm type (e.g. Wrn, Sd, BOC).
Alarm type is selected by user during the configuration of binary or analog user protection. Then the alarm
name follows, which can be adjusted by user during the configuration.
ECU alarms
The ECU alarms are received from the ECU. The alarms are represented by the Diagnostic Trouble Code,
which contains information about the subsystem where the alarm occurred, the alarm type and the alarm
occurrence counter.
The most common fault codes are translated into text form. Other fault codes are displayed as a numeric
code and the engine fault codes list must be used to determine the reason.
Built-in alarms
Events specification
Protection
type
Description
Wrn Battery Overvoltage WRN
Battery voltage is out of limits given by Battery Overvoltage
(page 253) setpoint.
Wrn Battery
Undervoltage
WRN
Battery voltage is out of limits given by Battery
Undervoltage (page 252) setpoint.
Sd Battery Flat SD
If the controller switches off during starting sequence (
STARTER (PAGE 501) output is active) it doesn't try to start
again and activates this protection (controller assumes bad
battery condition).
Sd Start Fail SD
Gen-set start failed. All crank attempts were tried without
success.
BOC Gen Lx
Undervoltage
Sd Gen Lx Overvoltage
(where x=1,2,3)
SD
BOC
The generator voltage is out of limits given by Generator
Undervoltage BOC (page 265) and Generator
Overvoltage Sd (page 264) setpoints.
BOC Gen V Unbalance BOC
The generator voltage is unbalanced more than the value of
Voltage Unbalance BOC (page 266) setpoint.
