Nominal Power Split Phase
Setpoint group Basic settings Related FW 1.3.0
Range [units] 1 .. 5 000 [kW]
Default value 200 kW Alternative config YES
Step 1 kW
Comm object 9977 Related applications AMF,MRS
Config level Standard
Setpoint visibility Conditioned by the setpoint Connection type (page 209)
Description
Nominal power of the Gen-set for detected split-phase or mono phase connection. Generator Overload
BOC (page 260) protection is based on this setpoint.
Note: This setpoint is used when setpoint Connection type (page 209) is adjusted to Autodetect and
Autodetect detects connection type as Monophase or Splitphase.
Note: To lock this setpoint against editing you also have to lock setpoint Nominal Power Split Phase
1 (page 377), Nominal Power Split Phase 2 (page 382) and Nominal Power Split Phase 3 (page
387).
6 back to List of setpoints
Subgroup: Current settings
Nominal Current
Setpoint group Basic settings Related FW 1.3.0
Range [units] 1 .. 10 000 [A]
Default value 350 A Alternative config YES
Step 1 A
Comm object 8275 Related applications AMF,MRS
Config level Standard
Setpoint visibility Conditioned by the setpoint Connection type (page 209).
Description
It is current limit for mains current protections and means maximal continuous mains current. Nominal
Current can be different from mains rated current value.
Note: To lock this setpoint against editing you also have to lock setpoint Nominal Current 1 (page
374), Nominal Current 2 (page 379) and Nominal Current 3 (page 384).
