InteliLite4 AMF20 Global Guide
270
MCB Close Delay
Setpoint group Mains Settings Related FW 1.3.0
Range [units] 0.0 .. 600.0 [s]
Default value 1.0 s Alternative config NO
Step 0.1 s
Comm object 8389 Related applications AMF
Config level Standard
Setpoint visibility Conditioned by the setpoint Default Application Select (page 217)
Description
Delay after mains returns to MCB closing, if the Gen-set is not running (e.g. is in start-up procedure).
6 back to List of setpoints
Transfer Delay
Setpoint group Mains Settings Related FW 1.3.0
Range [units] 0.0 .. 600.0 [s]
Default value 1.0 s Alternative config NO
Step 0.1 s
Comm object 8303 Related applications AMF
Config level Standard
Setpoint visibility Conditioned by the setpoint Default Application Select (page 217)
Description
Transition Delay between power sources.
Delay after GCB opening to MCB closing during the return procedure. Delay after MCB opening to GCB
closing if the setpoint MCB Opens On (page 283) is set to GENRUN.
The time charts bellow show recommended setting of Transfer Delay setpoint.
If the Transfer Delay setpoint is set shorter than the time required for opening of the circuit breaker, the
controller closes GCB CLOSE/OPEN (PAGE 480) output straight away (100ms) after the MCB FEEDBACK
(PAGE 453) input deactivates.
