InteliLite Global Guide
316
Setpoint group General Analog Inputs Related FW 1.9.0
Range [units] the range is defined by analog sensor curve
Default value
the value is defined by
analog sensor curve
Alternative config NO
Step the step is defined by analog sensor curve
Comm object 14991 Related applications AMF, MRS
Config level Standard
Setpoint visibility Visible only if the logical binary output AIN SWITCH04 (PAGE 584) is configured
Description
Threshold level for switching the binary output AIN SWITCH 17 (PAGE 665) off. The value is measured from
AIN SWITCH 04 (PAGE 661) analog input.
Image 8.58 General analog input 4 switch
Analog Switch 17 Off
6 back to List of setpoints
General Analog Input 18
Setpoint group General Analog Inputs Related FW 1.9.0
Range [units] the range is defined by analog sensor curve
Default value
the value is defined by
analog sensor curve
Alternative config NO
Step the step is defined by analog sensor curve
Comm object 9310 Related applications AMF, MRS
Config level Standard
Setpoint visibility Visible only if the logical analog input AIN PROT18 (PAGE 657) is configured
Description
Warning or history threshold level for AIN PROT18 (PAGE 657).
Note: These setpoints are used only if LAI AIN PROT18 (PAGE 657) is adjusted to required protection
type. Otherwise these setpoints are useless.
Analog Protection 18 Wrn
6 back to List of setpoints
