InteliNano-NT Plus, SW version 2.0.1.x, ©ComAp – July 2015
10
4 Installation and wiring
Mounting 4.1
The controller is to be mounted onto the switchboard or genset control panel door. Mounting cut-out
size is 96x96mm. Use the screw holders included with the controller to mount the controller into the
door as described on pictures below.
Figure 4.1
INTELINANO
NT
‘S CHASSIS MOUNTING
