7 Inputs and Outputs
In the table below you can see which logical function can be assigned to physical binary or analog
input or binary output. Each logical input or output function has unique code. Input code’s firs letter is
“I” output code’s letter is “O”. Summary of all logical input function is in chapter Logical binary and
analog inputs, summary of logical output function is in Logical binary outputs.
Each logical binary input and output can be configured as Normally Open (NO) or Normally Close
(NC)
Inputs
Terminal
Type
Direction
Input function assignment
T07
binary
input/output
I00, I01, I04, I05, I06, I07, I10, I11, I12, I13, I14, I15, I20, I22,
I24, I29
T11
binary
input
I00, I01, I02, I03, I04, I05, I06, I07, I10, I11, I12, I13, I14, I15,
I20, I22, I24, I29
T12
binary
input
I00, I01, I04, I05, I06, I07, I10, I11, I12, I13, I14, I15, I20, I22,
I24, I29
T13
binary/analog
input
I00, I01, I04, I05, I06, I07, I10, I11, I12, I13, I14, I15, I20, I21,
I22, I23, I24, I25, I29
T14
binary/analog
input
I00, I01, I04, I05, I06, I07, I10, I11, I12, I13, I14, I15, I20, I21,
I22, I23, I24, I25, I29
T15
binary/analog
input
I00, I01, I04, I05, I06, I07, I10, I11, I12, I13, I14, I15, I20, I21,
I22, I23, I24, I25, I29
Outputs
Terminal
Type
Direction
Input function assignment
T04
binary
output
O00, O01, O02, O03, O04, O05, O06, O07, O08, O09, O10,
O11
T05
binary
output
O00, O02, O03, O04, O05, O06, O07, O08, O09, O10, O11
T06
binary
output
O00, O02, O03, O04, O05, O06, O07, O08, O09, O10, O11
T07
binary
input/output
O00, O02, O03, O04, O05, O06, O07, O08, O09, O10, O11
T08
binary
output
O00, O02, O03, O04, O05, O06, O07, O08, O09, O10, O11
T09
binary
output
O00, O02, O03, O04, O05, O06, O07, O08, O09, O10, O11
NOTE:
All inputs except for Fuel Level Analog, Coolant Temperature Analog and Oil Pressure Analog
can be configured to the InteliNano
NT
controller terminal number T11, T12, T13, T14, T15 and shared
input/output terminal T07. All outputs exceptStarter, can be configured to terminal T04, T05, T06,
T07, T08 and T09. Binary output Starter can be configured only to high current output terminal T04.
