Binary inputs 4.8
Use minimally 1 mm
2
cables for wiring of standard binary inputs.
NOTE:
Logical binary functions for each binary input have to be assigned during the configuration.
+ -
4K7
5V Out
CPU
Figure 4.18
RECOMMENDED BINARY INPUTS WIRING
