12 Alarms, Events and History
Management
Following alarms and records are available:
 Event
 Warnings
 Shutdowns
 ECU Messages
Four records can be displayed simultaneously on the LCD screen. Total capacity is 10 records. The
Figure 12.1 is an example of how the history is organized. The last screen in this example is showing
the four latest events.
To view further history records press ▼ button see Figure 12.1.For alarm (shutdown) confirmation press
Stop button.
Figure 12.1
