ComAp InteliNano NT Plus

InteliNano-NT Plus, SW version 2.0.1.x, ©ComAp – July 2015
15
Voltage measurement and generator connection types 4.6
WARNING!
Risk of personal injury due to electric shock when manipulating the voltage terminals under voltage!
Be sure the terminals are not energized before beginning work.
Use 1.5 mm
2
cables for voltage measurement connection.
There are several voltage measurement connections for two different applications AMF and MRS. For
more details see table below.
Application type
Mains Connection Type
Generator Connection Type
AMF
3 Phase 4 Wires
Line to Line
3 Phase 3 Wires
Line to Line
Split Phase
Line to Line
Mono Phase
Line to Neutral
MRS
-
3 Phase 4 Wires
-
3 Phase 3 Wires
-
Split Phase
-
Mono Phase
