ComAp InteliNano NT Plus

InteliNano-NT Plus, SW version 2.0.1.x, ©ComAp – July 2015
88
Physical dimensions 13.3
Dimensions
118x108x40mm (WxHxD)
Weight
Mounting cutout size
96x96mm (WxH)
Recommended torque for
holders
15 – 20 cN*m
Binary inputs 13.4
Number of binary inputs
up to 6
Galvanic insulation
Not insulated
Closed contact voltage
<2V
Open contact voltage
>3,5V
Input resistance
1,5 kΏ
Binary outputs 13.5
Total number of binary
outputs
up to 6*
Number of low current
binary outputs
4
Number of high current
binary outputs
2
Galvanic insulation
Not insulated
Type
Transistor, switching to positive supply terminal
Operating voltage
8-36VDC
Switching current of low
current binary output
500mA (suppression diodes required for inductive loads)
Switching current of high
current binary output
6A - long term (Maximum load inductance is 500mH,
10A - short term suppression diodes required for inductive
loads!)
Total output current
10A – long term
15A – short term
NOTE:
One low current (500mA) binary output – T07 can be configured as binary input .
