ComAp InteliNano NT Plus

InteliNano-NT Plus, SW version 2.0.1.x, ©ComAp – July 2015
29
6 Controller Settings
Setup mode 6.1
CAUTION!
Controller must be in manual mode before you can enter the controller’s setup mode. Use button Auto
for switching between Auto and Manual mode. Green LED above button Auto is turned off when the
controller is in Manual mode.
If you have not configured custom initialization (init) screen then press and hold Stop button, then
briefly press ▲ button then Auto (Figure 6.1).
press and hold + press
hold + press
Figure 6.1
ENTRY TO SETUP MODE (WITHOUT CUSTOM SCREEN)
If you have already created your own init screen then press and hold Stop button and then press
briefly press ▲, the custom init screen will appear, keep holding the Stop button. Then press ▼ to
switch LCD to default init screen and then press Auto (Figure 6.2).
