Low Power Outdoor (LPOD) Amplifier/Block Up Converter (BUC)
Revision 15
Serial Interface Operation 5–39 MN-LPOD
Parameter
Type
(* indicates
End-of-Life)
Controller-to-Target
Instruction Code and
Qualifier
Arguments
for Command
or Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 to 57)
Target-to-Controller
(see Description of
Arguments)
Command Query
Response to
Command
Response
to Query
SNMP System
Location
SSL=
SSL?
255 bytes,
characters
Command or Query.
Sets or returns the SNMP System Location string.
COMMAND EXAMPLE: <0001/SSL=Upstairs back right.
NOTE: When not configured, the target returns an empty string.
<0001/SSL={CR}{LF}
SSL =
SSL!
SSL=x[1..1
28]
SNMP Unit
Name
SSN=
SSN?
16 bytes,
characters
Command or Query.
Sets or returns the SNMP Unit Name string.
COMMAND EXAMPLE: <0001/SSN=Remote1{CR}
NOTE: When not configured, the target returns an empty string.
<0001/SSC={CR}{LF}
SSN =
SSN!
SSN=x[1..1
28]
SNMP Trap
Destination IP
Address 1
STA=
STA?
15 bytes,
Numerical
Command or Query.
Sets or returns the IP Address of the SNMP Trap Destination IP Address 1 (where
traps will be sent first) in the form xxx.xxx.xxx.xxx, where:
xxx.xxx.xxx.xxx=IP Address
COMMAND EXAMPLE: <0001/STA=010.006.030.001{CR}
NOTE: When not configured, the target returns >0001/STA=0.0.0.0{CR}{LF}
STA =
STA!
STA=xxx.x
xx.xxx.xxx
SNMP Trap
Destination IP
Address 2
STB=
STB?
15 bytes,
Numerical
Command or Query.
Sets or returns the IP Address of the SNMP Trap Destination IP Address 2 in the
form xxx.xxx.xxx.xxx, where:
xxx.xxx.xxx.xxx=IP Address
COMMAND EXAMPLE: <0001/STB=010.006.030.002{CR}
NOTE: When not configured, the Target returns >0001/STB=0.0.0.0{CR}{LF}
STB =
STB!
STB=xxx.x
xx.xxx.xxx
SNMP Trap
Version
STV=
STV?
1 byte
Command or Query.
Sets or returns the SNMP Trap Version that will be used to send traps in the form
x, where:
1=SNMP Trap Version 1
2=SNMP Trap Version 2
COMMAND EXAMPLE: <0001/STV=0{CR}
STV =
STV!
STV=x
