LPOD C- / Ku-Band Outdoor Amplifier/ Block Up Converter (BUC) Revision 3
Appendix B MN-LPOD
B–17
Parameter Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
(Note that all arguments are printable ASCII
characters)
Response to
Command
(Target to Controller)
Query
(Instruction
Code and
qualifier)
Response to
Query
(Target to
Controller)
Global Amplifier
Configuration
GAC= 43 bytes Command or Query.
Used to set up and query the global status of the
BUC/SSPA with a semicolon delimited string of data.
Example (set GAC):
GAC=a;b;cc.cc;dd.dd;e;fffff;g;hh;I;j;k;l;m;n;o;’cr’
Where:
a = redundancy mode (ESW)
b = online status (ONL)
cc.cc = Attenuation Offset (AOF)
dd.dd = Customer Attenuation(ATT)
e = Auto Fault Recovery (AFR)
fffff = Unit Alarm Mask (MSK)
g = LNB Current Source (LCS)
hh = LNB Current Window (LCW)
i = LNB Current Window Enable (CWE)
j = Enable Statistics Averaging (ESA)
k = Set Statistics Interval (SSI)
l = Enable Statistics Logging (ESL)
m = Auxiliary Mute (AUX)
n = user mute state (MUT)
o = RF power amplifier state (AMP)
GAC=
GAC*
GAC?
GAC#
GAC? GAC=x….x
(See Description
of Arguments for
details)
Initialize Events
Pointer
IEP= None Command only.
Resets internal pointer to allow RNE? Queries to start
at the beginning of the stored events log.
Example: <1/IEP=’cr’
>0001/IEP=’cr’lf
IEP=
IEP?
IEP*
N/A N/A
Software Image IMG= 1 byte
Command or Query.
Current Active software image, where:
1=Bulk Image # 1 currently active
2=Bulk Image # 2 currently active
Examples:
<1/IMG=1’cr’ (instructs the unit to load firmware from
image #1 at the next reset / power up).
<1/IMG?’cr’ (queries the image number that the
firmware loaded during bootup)
Note: if you send the IMG command, and then query
the IMG value the numbers may not be equal because
the command tells the firmware which image to boot
from at the next bootup, and the query reports the image
that the firmware booted from on the last bootup.
IMG=
IMG?
IMG*
IMG#
IMG?
IMG=x
(See description
of arguments)
