45
steam-prod[kg/h]
ref.=50/act=25
– Steam production
Currentactualandnominalvalueofsteamproductioninkg/h.
– Nominalvalue:max.unitcapacityxinputsignalvalue
Note:ifacapacitylimitationissetthenominalvalueisgiveninbrackets
– Actualvalue:max.unitcapacityxinputsignalvaluexcapacitylimitation
Note:iftheinternalcontrollerisactivatedonlytheactualvalueisshown.
Underthefollowingconditionstheactualvaluemaydifferfromthenominal
value:uponactivationoftheheatingpower,ifcapacitylimitationisactive,dur-
ingthellingcycleofthesteamcylinder.
– Analog input (humidity demand)
Currentvalueofthesignalappliedtotheanaloginputin%ofitsmax.value.
Note: If the internal controller is active the displayed value corresponds to the
currentairhumidity(%rh).
– Internal controller
Internal controller activated (“on”)/deactivated(“off”).
Note: The internal controller can be activated on the setting level (see chap-
ter6.5).
– Nominal value of relative humidity
Selected value of relative humidity in %rh.
Note: This option is available only if the internal controller is active.
– Proportional range of the internal controller
Selectedproportionalrange(P-Range)oftheinternalcontrollerin%.
Note: This option is available only if the internal controller is active.
– Integral time of the internal controller
Selected integral time of the internal controller in minutes.
Note: This option is available only if the internal controller is active.
– Working hours
Totalofworkinghourselapsedsinceinitialcommissioningofthesteamhu-
midier.
– Time remaining to small/extended maintenance
Thetimeremaining(inhours)beforethenextsmall/extendedmaintenance.
Note: The stated times are based on 100 % steam capacity. If the operation is
atalessercapacity,thetimeshouldbeextendedaccordingly.Themaintenance
intervalsaresetusingtherotaryswitch“S2”onthecontrolboard.Pleasepay
attention to the notes in chapter 6.1.
Description of the operating parameters on the display level
Thefollowingdescribestheindividualoperatingparametersthatcanbeselectedusingthekeys<B>
and <A> , after the display level has been called-up.
analog input [%]
25
controller funct
on
ref.value rh [%]
45
P-band [%]
30
Integr.time[min]
10
elapsed time
623
time to mainten.
600/1200
