Drawings and dimension
7.1 IPefono Wall Mount
IPefono-WM
172
,
0
m
m
102,0 mm
33,0 mm
16,0 mm
5
3
,
0
m
m
53,0 mm
13 mm
19,9 mm
54,9 mm
2
0
,
5
m
m
3 mm
58,0 mm
61,0 mm
KEYBOARD
PUSH BUTTON
34,0 mm
