Contex COUGAR 36 - LED Indicators on Operator Panel

FSG/MTM/001 060511
143
Fig. 6-1 SM Calibration Sheet, 25”
IT8-Sheet and
patterns faces
outwards when
folded
AGFACOLORIT8
Do wn
W: xx .x: -x.x:x.x B:xx.x: -x.x:x.x
C90701xx.it8
Black Calibration Area
Must not contain dirt or scratches
White Calibration Area
Must not contain dirt or scratches
