FSG/MTM/001 060511
144
Fig. 6-2 SM Calibration Sheet, 40”
AGFACOLORIT8
Do wn
W: x x.x: -x.x :x.x B:xx .x: -x.x:x.x
C90701xx.it8
IT8-Sheet and
patterns faces
outwards when
folded
White Calibration Area
Must n ot conta in dirt or scra tches
Black Calibration Area
Must n ot conta in dirt or scra tches
Gray Calibration Area
Must n ot conta in dirt or scra tches
Gray Calibration Area
Must n ot conta in dirt or scra tches
Gray Calibration Area
Must n ot conta in dirt or scra tches
To Next Page
