Fig. 6-3 SM Calibration Sheet, 54”
AG FACO LO RIT 8
Down
W: xx.x: - x. x:x.x B :xx.x: -x.x:x. x
C 90 701 x x . it 8
IT8-Sheet and
patterns faces
outwards when
folded
White Calibration Area
Must not contain dirt or scratches
Black Calibration Area
Must not contain dirt or scratches
Gray Calibration Areas
Must not contain dirt or scratches
