Control Techniques Mentor MP User Manual

Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
Menu 8
Mentor MP Advanced User Guide 121
Issue Number: 4 www.controltechniques.com
OFF (0) = Terminal is an input
On (1) = Terminal is an output
When the 24 V input terminal is above 21.6 V, this parameter is 1.
When this parameter is 1 the output changes state on each non-active to active change on the key.
8.31 T24 digital I/O 1 output select
8.32 T25 digital I/O 2 output select
8.33 T26 digital I/O 3 output select
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default See Table 5-7
Update rate Background read
8.40 T61, T62, T63 relay state
8.41 Start button state
8.42 Forward / Reverse button state
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Default See Table 5-7
Update rate 4 ms write
8.48 24V input state
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Update rate Background write
8.50 T61, T62, T63 relay invert
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate 4 ms write
8.52 Toggle enable
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate Background read
8.60 T61, T62, T63 relay source
8.61 Start button destination
8.62 Forward / Reverse button destination
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21111
Default See Table 5-7
Range Pr 0.00 to Pr 22.99
Update rate Read on drive reset
