Control Techniques Mentor MP User Manual

Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
Menu 3
Mentor MP Advanced User Guide 49
Issue Number: 4 www.controltechniques.com
The hard speed reference is a reference value which does not pass through the ramp system (Menu 2). It is added to the normal post ramp speed
reference. Its value may be written from the keypad, via serial comms, from an analog input or from an encoder input. This parameter can also be
used by the position controller (Menu 13) as the speed reference input. The hard speed reference is selected when Pr 3.23 = 1.
0, drv: Drive encoder
The position feedback from the encoder connected to the drive itself is used to derive the speed feedback for the speed controller.
1, Slot1: Solutions Module in slot 1
The position feedback from the option module in option module slot 1 is used to derive the speed feedback for the speed controller. If a position
feedback category option module is not installed in slot 1 the drive produces an Enc9 trip if the drive is active.
2, Slot2: Solutions Module in slot 2
3, Slot3: Solutions Module in slot 3
4, tACHO: Tachometer
5, ESt.SPEED: Estimated speed
Provided the setup parameters for the drive encoder are correct this parameter shows the encoder speed in rpm.
It should be noted that the value shown by this parameter is measured over a 16 ms sliding window period (in the same way as Pr 3.02 {di05, 0.40}),
and so the ripple in this parameter accessible via comms or by an Solutions Module is as defined for Pr 3.02 {di05, 0.40}. The FI attribute for this
parameter is set, and so further filtering is applied when this parameter is viewed with one of the drive keypads.
This is used in conjunction with Pr 3.29. See the description under Pr 3.29 overleaf.
3.23
Hard speed reference selector
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate 4 ms read
3.26
{Fb01, 0.71}
Speed feedback selector
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111
Range 0 to 5
Default 5
Second motor
parameter
Pr 21.21
Update rate Background read (Only has any effect when the drive is disabled)
3.27
{Fb09, 0.79}
Drive encoder speed feedback
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11111
Range ±10,000.0 rpm
Update rate 4 ms write
3.28
Drive encoder revolution counter
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range ±32,678 revolutions
Update rate 4 ms write
