Convaid Flyer - Table of Contents

ii
CONVAID USER’S GUIDE
Product Overview
Denition of Symbols…………………………………………………... ……………………… 1
Warnings…………………………………………………………………..………………………... 3
Flyer Standard Features Overview……………………………………………………….... 8
Seating Module Standard Front and Back……………………………………………… 9
Seating Module with Pans……………………………………………………………………. 10
Flyer Specications…………………………………………………………………..…………. 11
Annex A Information Disclosure……………………………………………………………. 12
Setting Up
Contents in the Box………………………………………………………..……………………. 14
How To Remove Chair from Box…………………………………….....…………………… 14
Preparing the Chair for Use……………………………………………..…………………… 14
Tools Required……………………………………………..……………………………………… 14
Unfolding the Chair ……………………………………………..……………………………… 15
Folding/Unfolding the Seating Module……………………………………….............. 15
Lifting/Carrying the Seating Module………………………………………................. 17
Lifting/Carrying the Mobility Base………………………………………..................... 17
Installing Seating Module onto Mobility Base………………………………………... 18
Removing Seating Module from Mobility Base……………………………………….. 19
Fitting Guide
Seat Back Height……………………………..........................................………………. 20
Back Height Adjustment…………………………….................................................. 20
Seat Depth Adjustment…………………………….................................................... 21
Seat Width Adjustment………………......................................…………….............. 24
Mobility Base Width………………......................................……………................... 27
Mobility Base Width Adjustment……………………………………………………......... 27
Tilt-In-Space Adjustment………………......................................……………............ 27
Cross Tube Adjustment on Back Canes………………......................................… 28
Recline Adjustment………………......................................…................................. 29
Positioning Belts………………......................................…..................................... 30
Pelvic Positioning Belts………………......................................….......................... 30
Two-Point Positioning Belt………………......................................…..................... 30
Seat Tube Mount………………......................................…..................................... 30
Back Cane Mount………………......................................….................................... 31
Back Pan Mount………………......................................…...................................... 31
Footplate Adjustment………………......................................…..............…............ 32
Foot Positioners………………......................................…..............…............…...... 33
Wheels
Wheel Specications……………………………………………………..………………….… 34
Wheel Lock Operation……………………………………………………..…………………... 34
Removal & Installation of Rear Wheels…………………………………………………. 35
Table of Contents
