Product Manual – DOC. 8432A Crestron Pyng OS 2 for CP4-R • 157
NOTE: All On and All Off lighting scenes may not be deleted in user control mode.
Tap the back arrow button to return to the lights screen.
Shades
Tap the Shades button on the Home screen or select Shades from the Devices
section of the user menu to display the shades screen.
Basement Screen - Shades
Use the shades screen to select and play any shade scene or group in the Crestron Pyng
system. The shades screen also allows the homeowner to add and edit shade scenes. This
process is similar to creating shade scenes in the setup pages.
Use the drop-down menu on the top left of the screen to select a room that contains a
shade scene. Only rooms with shade scenes or loads may be selected from the menu.
Any shade groups configured for the room appear in the left screen panel.
• Tap the closed shade button to lower a shade group fully (0%).
• Tap the down button (v) to lower a shade group incrementally.
• Tap the up button (^) to raise a shade group incrementally.
• Tap the open shade button to open a shade group fully (100%).
