228 • Crestron Pyng OS 2 for CP4-R Product Manual – DOC. 8432A
Remote Control Button Mapping (continued)
BUTTON
PYNG
COMMAND
DRIVER
COMMAND
TSR-310
SUPPORT
HR-310
SUPPORT
HR-150
SUPPORT
HR-100
SUPPORT
The first of these
available commands for
the device: Home, Menu,
TopMenu
Home, Menu, TopMenu Yes
Yes
No No
VolumeUp VolumeUp Yes
Yes
Yes Yes
ToggleMute Mute Yes
Yes
No No
MUTE
ToggleMute Mute No
No
Yes Yes
VolumeDown VolumeDown Yes
Yes
Yes Yes
ChannelUp ChannelUp Yes
Yes
Yes Yes
Info Info Yes
Yes
No No
INFO
Info Info No
No
Yes Yes
ChannelDown ChannelDown Yes
Yes
Yes Yes
MENU
The first of these
available commands for
the device: Menu, Home,
TopMenu
Home, Menu, TopMenu Yes
Yes
Yes Yes
GUIDE
The first of these
available commands for
the
device: Guide, Home,
TopMenu
Guide, Home, TopMenu Yes
Yes
Yes Yes
Directional
pad,
normal
(non-color
button)
mode
Up, Right, Down, Left Up, Right, Down, Left Yes
Yes
Yes Yes
Directional
pad, color
button
mode
Green, Red, Yellow, Blue Green, Red, Yellow, Blue Yes
Yes
No No
Directional
pad, center
button
Select Select Yes
Yes
No No
Directional
pad,
SELECT
Select Select No
No
Yes Yes
EXIT
The first of these
available commands for
the device: Exit, Back
Exit, Back Yes
Yes
Yes Yes
(Turns on the direction
al
pad's color button
mode)
Not applicable Yes
Yes
No No
(continued on following page)
