CS Instruments LD 500 User Manual

Operation
LD500 V2.03 Seite 15 von 67
11.3 Home menu LD 500
The operation is largely self-explanatory and menu-driven via the touch panel.
The selection of the respective menu items occur via short "tapping" with the finger or a soft round pen.
Attention: Please use no pens or other objects with sharp edges!
The foil can be damaged!
Before the leakage search is started, the device must be configured. The user can access the menu by
clicking the "Home" button. The following figure shows the Home "Menu".
Home
With the button „Home“ you access the basic
menu of the LD 500.
Return to measurement by pressing
„Leakage“ –button.
