Dew point sensor FA5xx
LD500 V2.03 Seite 43 von 67
13.5.1 Settings Dew point sensor FA 500 / FA 510
13.5.1.1 Unit selection for temperature and humidity
External sensor ➔ Settings ➔ Sensor settings ➔ C1➔ arrow right (2.page)
13.5.1.2 Definition of the System pressure (relative pressure value)
External sensor ➔ Settings ➔ Sensor settings ➔ C1➔ arrow right (2.page)➔Pressure Setting
The system pressure is inserted by entering
the values in the corresponding text field.
The unit can be freely selected, selection
menu is opened by pressing the
corresponding button units
Confirm the settings by pressing the OK
button.
Unit selection for temperature and
humidity by pressing the button °C, °F,
g/m³ or mg/m³.
Confirm the settings by pressing the OK
button.
