Settings
LD500 V2.03 Seite 33 von 67
11.3.4.2.10 Set backlight brightness
Home ➔Settings ➔ Set backlight
Remark:
At the first touch, the Backlight in our example is reset to 39%, after that a "normal" function
operation is possible.
Important:
If the Backlight dimming after button is not activated, then the Backlight stays permanently
on, in the currently set brightness.
Here you adjust the desired Backlight
(15-100%) of the display directly.
E.g. Backlight to 39 %
With the help of the Backlight dimming after
button, after a definable time interval (here
after 15 minutes), the Backlight can be
reduced to the minimum.
As soon as the dimmed screen is operated
again, the Backlight is committed
automatically on the last set value before
dimming.
To reduce the energy consumption (device
runtime), you can switch off the display
backlight by setting "Backlight off after".
