Device controls

LD500 V2.03 Seite 8 von 67

8 Device components and controls

8.1 The LD 500

3.5mm jack for the

headphone

Acoustic trumpet

Camera

USB connection

Plug-in connection for

power supply (battery

charger socket)

Save button

Volume (+/-)

On/Off button

Foil keypad (4 buttons)

Unlock button for preamp

module

Preamp module

3.5" TFT colour display

with touch panel
