Input Signals ext. sensor
LD500 V2.03 Seite 37 von 67
13.2 Input signals of ext. sensor LD510
13.3 Cable cross section
13.3.1 Sensor circuit points/Output signal:
AWG26, cable cross-sections: 0.14 mm
2
Input signals
Current signal
(0 – 20 mA / 4 – 20 mA)
internal or external
power supply
Measuring range
0 – 20 mA / 4 – 20 mA
Resolution
0,0001 mA
Accuracy
 0,03 mA  0,05 %
Input resistance
50 
Voltage signal
(0 - 1V)
Measuring range
0 - 1 V
Resolution
0,05 mV
Accuracy
 0,2 mV  0,05 %
Input resistance
100 k
Voltage signal
(0 - 10 V / 30 V)
Measuring range
0 - 10 V/30 V
Resolution
0,5 mV
Accuracy
 2 mV  0,05 %
Input resistance
1 M
RTD
Pt100
Measuring range
-200 - 850 °C
Resolution
0,1 °C
Accuracy
 0,2 °C at -100 - 400 °C
 0,3 °C (further range)
RTD
Pt1000
Measuring range
-200 - 850 °C
Resolution
0,1 °C
Accuracy
 0,2 °C at -100 - 400 °C
 0,3 °C ( further range )
Pulse
Measuring range
minimal pulse length 100 μ s
frequency 0 - 1 kHz
max. 30 VDC
