Charging the batteries
LD500 V2.03 Seite 35 von 67
12 Charging the batteries
The battery is charged within the device. For this, the supplied plug-in power supply is connected to the
built-in charging socket of the LD 500 and the 230V socket.
The LD 500 checks the charging status of the battery and starts the charging process automatically if
necessary.
To protect the Li-ION accumulator of exhaustive discharge the device is switching off automatically if a
cell voltage of 6,4V will be reached.
Connect external power
supply to the charging socket.
Symbol „CHG“ is
displayed during
charging.
CHG
