CVC TECHNOLOGIES, INC. CVC 400 OPERATION MANUAL
3) Label sensitivity is set after the above two readout displays. After that, the display is changed to:
PLACE PRODUCT
ON CONVEYOR
FOR TEST
4) Place one product on the conveyor to the left of the product sensor when conveyor starts moving
slowly.
5) After the product passes through, the conveyor speed will increase, and two labels will be rapidly
dispensed (remove these labels) and the display will show this instruction:
READY TO START
6) After couples of seconds, the display will be changed to the following, which shows the machine is
ready to begin labeling job.
MEMORY: 00
F1 OUTPUT:
F2 REMING:
F3 PD SPD:
7) Set F2 which quantity of label roll if necessary. It shows remaining quantity of the label. A buzzer
sound will be heard to alert the operator when label remaining quantity fall to "500" and "200".
8) The machine stops automatically when label remaining quantity falls to "0". Normally F2 is set at "0"
if label remaining quantity is not necessary for operation.
9) SelfSet
TM
sets normal running speed. Operator can change speed if necessary. For labeling speed
adjustments, please refer to charter 11.
10) If the product is a clear bottle, enter bottle diameter (mm):
Use the key to search for the display which is shown as follows:
F1 PD LEN
F2 LA LEN
F3 LB LEN
10 - 3
