Label Sensor
Head B (Left, X1) <7P> Head A (Right, X2) <7P>
Pin No. Color Jump No. Definition Pin No. Color Jump No. Definition
1 RED
J32-4
DLAV1, Sending signal input
Label sensor
1 RED
J32-6
DLAV2, Sending signal input
Label sensor
2 WHT
J32-2
DC 12VG, Sending power,
Label sensor
2 WHT
J32-2
DC 12VG, Sending power,
Label sensor
3 BLK
J32-5
VLSI1, Receiving signal output
Label sensor
3 BLK
J32-7
VLSI2, Receiving signal output
Label sensor
4 GRN
J32-3
DC 5V Receiving power
Label sensor
4 GRN
J32-3
DC 5V Receiving power
Label sensor
5 BRN
J31-2
DC 12V, Power
Clear label sensor
5 BRN
J31-2
DC 12V, Power
Clear label sensor
6 BLU
J31-3
DC 12VG, Power
Clear label sensor
6 BLU
J31-3
DC 12VG, Power
Clear label sensor
7 PPL
J31-9
Signal output
Clear label sensor
7 PPL
J31-10
Signal output
Clear label sensor
Hot Stamp Printer (optional)
Labeling Head B (Left, X1) <8P> Labeling Head A (Right, X2) <8P>
Pin No. Color Jump No. Definition Pin No. Color Jump No. Definition
1 BRN J31-2
DC 12V Sensor power
(No ribbon or no print sensor)
1 BRN J31-2
DC 12V Sensor power
(No ribbon or no print sensor)
2 GRN J33-7
DC 24VG
2 GRN J33-7
DC 24VG
3 RED J33-12
Printing signal output
3 ORG
J33-15
Printing signal output
4 PPL J32-11
Detecting input
No ribbon or no print sensor
4 PPL
J32-10
Detecting input
(No ribbon or no print sensor)
5 BLU J31-3
DC 12VG Sensor power
(No ribbon or no print sensor)
5 BLU J31-3
DC 12VG Sensor power
(No ribbon or no print sensor)
6 WHT J30-2
AC OUT+ 110V
Power, printer
6 WHT J30-2
AC OUT+ 110V
Power, printer
7 BLK J30-3
AC OUT- 110V
Power, printer
7 BLK J30-3
AC OUT- 110V
Power, printer
8 YEL
J33-6 DC 24V
8 YEL
J33-6 DC 24V
