CVC TECHNOLOGIES, INC. CVC 400 OPERATION MANUAL
14 - 5
Digital Sensor
Product Sensor <3P> P&P Sensor <3P>
Pin No. Color Jump No. Definition Pin No. Color Jump No. Definition
1 BRN
J31-2 DC 12V
1 BRN
J31-2 DC 12V
2 BLU
J31-3 DC 12VG
2 BLU
J31-3 DC 12VG
3 BLK
J31-11
Signal cable
3 BLK
J31-12 Signal cable
Backlog & Wrapping Sensor
Backlog Sensor <4P> Wrapping Sensor <4P>
Pin No. Color Jump No. Definition Pin No. Color Jump No. Definition Pin No. Color Jump No. Definition
1 BRN
J31-1 DC 12V
2 BLU
J31-4 DC 12VG’
3 YEL
J32-12 Sensor out
4
