8D-Link ShareCenter DNS-320L User Manual
Section 1 - Product Overview
Power:
Solid Blue - the device is on
Blinking Blue - the device is booting or restarting
No Light - the device is o or in power saving mode
LED Description
USB:
Solid Blue - USB Storage is connected
Blinking Blue - transferring data, or a USB device is being
installed or unmounted
Solid Orange - USB storage failed to mount
No Light - No USB storage or the device is o
HDD (Left/Right):
Solid Orange - the specied hard drive has a problem
No Light - the specied hard drive is inactive
Solid Blue - the specied hard drive is functioning correctly
Blinking Blue - there is reading / writing / hot-swapping
activity on the specied hard drive

Table of Contents

Other manuals for D-Link DNS-320L

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DNS-320L and is the answer not in the manual?

D-Link DNS-320L Specifications

Power IconPower
power supplyExternal DC 12 V / 3 A
power saving modeAuto power recovery
scheduled power offSupported
Operating Environment IconOperating Environment
operating temperature32 to 104 ˚F (0 to 40 ˚C)
storage temperature-4 to 158 ˚F (-20 to 70 ˚C)
humidity5% to 90% non-condensing
Ports & Interfaces IconPorts & Interfaces
ethernet port1 x 10/100/1000 Gigabit
usb port1 x USB 2.0
connection to UPSSupported through USB port
Weight and Dimensions IconWeight and Dimensions
weight0.25 lbs
dimensions3.54” x 5.68” x 7.6”
dimensions (mm)90 x 144.3 x 193.3 mm
