D-Link DNS-320L User Manual

20D-Link ShareCenter DNS-320L User Manual
Section 3 - Installation
To run the setup wizard, insert the ShareCenter CD into your CD-ROM drive.
When the autorun screen appears, click Install
Note: Windows Firewall may present you with a warning message to unblock
the device. Click Allow Access to allow your computer access to the NAS.
Select the language of your choice and then click the Start button.
Windows Installation
Setup Wizard

D-Link DNS-320L Specifications

Power

power supply	External DC 12 V / 3 A
power saving mode	Auto power recovery
scheduled power off	Supported

Operating Environment

operating temperature	32 to 104 ˚F (0 to 40 ˚C)
storage temperature	-4 to 158 ˚F (-20 to 70 ˚C)
humidity	5% to 90% non-condensing

Ports & Interfaces

ethernet port	1 x 10/100/1000 Gigabit
usb port	1 x USB 2.0
connection to UPS	Supported through USB port

Weight and Dimensions

weight	0.25 lbs
dimensions	3.54” x 5.68” x 7.6”
dimensions (mm)	90 x 144.3 x 193.3 mm
