D-Link DNS-320L User Manual

175D-Link ShareCenter DNS-320L User Manual
Section 4 - Conguration
iTunes Server
The DNS-320L features an iTunes Server. This server provides the ability to share music to computers on the local network
running iTunes. If the server is enabled, the device will be automatically detected by the iTunes program and the music con-
tained in the specied folder will be available to stream over the network. Click the Refresh button to update all the shared
les and folder lists. To access the conguration, click on Application Management>>Multimedia Services and expand
the iTunes Server section by clicking on the blue arrow.
After enabling the iTunes server on the ShareCenter, launch iTunes. In your
iTunes utility, select the ShareCenter and enter the iTunes server password (if
required).
Select to enable or disable the iTunes Server.
Species the folder or directory that will be shared by the
iTunes server. Select root to share all les on all volumes, or
click Browse to select a specic folders.
Sets password for the iTunes server (optional).
Here the user can select the MP3 Tag Codepage used by
this device. Currently the Codepage is set to Western Euro-
pean.
Here the user can select the interval between automatically
refreshing the iTunes library.
iTunes Server:
Folder:
Password:
MP3 Tag
Codepage:
Auto Refresh:

D-Link DNS-320L Specifications

Power

power supply	External DC 12 V / 3 A
power saving mode	Auto power recovery
scheduled power off	Supported

Operating Environment

operating temperature	32 to 104 ˚F (0 to 40 ˚C)
storage temperature	-4 to 158 ˚F (-20 to 70 ˚C)
humidity	5% to 90% non-condensing

Ports & Interfaces

ethernet port	1 x 10/100/1000 Gigabit
usb port	1 x USB 2.0
connection to UPS	Supported through USB port

Weight and Dimensions

weight	0.25 lbs
dimensions	3.54” x 5.68” x 7.6”
dimensions (mm)	90 x 144.3 x 193.3 mm
