D-Link DNS-320L User Manual

11D-Link ShareCenter DNS-320L User Manual
Section 2 - Getting Started
Getting Started
Hardware Setup
This user guide will help you get your ShareCenter set up in just a few steps. To install the ShareCenter on your local net-
work, refer to the steps below, or skip to Zero Conguration Setup on page 14 to run the setup wizard which will show you
how to install and congure your DNS-320L.
Release the top panel by rmly pressing the latch at the back.
Once the faceplate is unlatched, remove it to expose the hard drive bays.

D-Link DNS-320L Specifications

Power

power supply	External DC 12 V / 3 A
power saving mode	Auto power recovery
scheduled power off	Supported

Operating Environment

operating temperature	32 to 104 ˚F (0 to 40 ˚C)
storage temperature	-4 to 158 ˚F (-20 to 70 ˚C)
humidity	5% to 90% non-condensing

Ports & Interfaces

ethernet port	1 x 10/100/1000 Gigabit
usb port	1 x USB 2.0
connection to UPS	Supported through USB port

Weight and Dimensions

weight	0.25 lbs
dimensions	3.54” x 5.68” x 7.6”
dimensions (mm)	90 x 144.3 x 193.3 mm
