267D-Link ShareCenter DNS-320L User Manual
Section 4 - Conguration
You can access the E-map from the Live Video screen by clicking the button. Note: you must have installed E-map JPEG
les in order to use this feature. Click the E-map Upload button to upload images into the database. When you click this
button you will be directed to the E-map Upload window.
My Surveillance - E-Map View
