D-Link DNS-320L User Manual

251D-Link ShareCenter DNS-320L User Manual
Section 4 - Conguration
My Music - Create a Playlist
Click the Playlist tab at the bottom of My Music.
The Create a New Playlist menu will appear. Enter a name under Playlist Name
and click the songs you wish to add to the playlist. Click Apply to add them to
the list.
Click the Plus icon at the top right-hand corner.

D-Link DNS-320L Specifications

Power

power supply	External DC 12 V / 3 A
power saving mode	Auto power recovery
scheduled power off	Supported

Operating Environment

operating temperature	32 to 104 ˚F (0 to 40 ˚C)
storage temperature	-4 to 158 ˚F (-20 to 70 ˚C)
humidity	5% to 90% non-condensing

Ports & Interfaces

ethernet port	1 x 10/100/1000 Gigabit
usb port	1 x USB 2.0
connection to UPS	Supported through USB port

Weight and Dimensions

weight	0.25 lbs
dimensions	3.54” x 5.68” x 7.6”
dimensions (mm)	90 x 144.3 x 193.3 mm
