D-Link DNS-320L User Manual

52D-Link ShareCenter DNS-320L User Manual
Section 3 - Installation
Mac - Setup Wizard Installation
To run the Setup Wizard, insert the ShareCenter CD into your CD-ROM drive.
Double-click the SetupWizardDNS icon.
When the autorun screen appears, double-click the .dmg le.
Click Start to begin the wizard. Follow the instructions on the screen to nish
setting up your DNS-320L. For more details, refer to Setup Wizard on page 20.

D-Link DNS-320L Specifications

Power

power supply	External DC 12 V / 3 A
power saving mode	Auto power recovery
scheduled power off	Supported

Operating Environment

operating temperature	32 to 104 ˚F (0 to 40 ˚C)
storage temperature	-4 to 158 ˚F (-20 to 70 ˚C)
humidity	5% to 90% non-condensing

Ports & Interfaces

ethernet port	1 x 10/100/1000 Gigabit
usb port	1 x USB 2.0
connection to UPS	Supported through USB port

Weight and Dimensions

weight	0.25 lbs
dimensions	3.54” x 5.68” x 7.6”
dimensions (mm)	90 x 144.3 x 193.3 mm
