D-Link DNS-320L User Manual

338D-Link ShareCenter DNS-320L User Manual
Section 4 - Conguration
MTP Backups
MTP
Backups:
Destination:
Status:
Click Enable to allow your ShareCenter to copy digital media
content from a MTP USB device.
Click Browse to select a folder on your ShareCenter for the
backup data to be saved to.
Displays the current MTP backup status.
Click on the Save Settings button to save the MTP Backups
settings.

D-Link DNS-320L Specifications

Power

power supply	External DC 12 V / 3 A
power saving mode	Auto power recovery
scheduled power off	Supported

Operating Environment

operating temperature	32 to 104 ˚F (0 to 40 ˚C)
storage temperature	-4 to 158 ˚F (-20 to 70 ˚C)
humidity	5% to 90% non-condensing

Ports & Interfaces

ethernet port	1 x 10/100/1000 Gigabit
usb port	1 x USB 2.0
connection to UPS	Supported through USB port

Weight and Dimensions

weight	0.25 lbs
dimensions	3.54” x 5.68” x 7.6”
dimensions (mm)	90 x 144.3 x 193.3 mm
