D-Link DNS-320L User Manual

276D-Link ShareCenter DNS-320L User Manual
Section 4 - Conguration
COMPONENT ICON DESCRIPTION
Recorded Video Playback View the recorded video here.
Playback Controls
Control the playback video from here (clockwise): Play/Stop/Pause/ Previous Second/Previous Min-
ute/Next Minute/Next Second / Speed Up/Speed Down / Zoom In/Zoom Out.
Camera Details
This area displays the time and date of the recording, the playback speed and the current state of
playback.
Enable Digital Zoom Enable this on individual cameras.
Mute and Volume Slider
The mute button can be used to mute the sound from the recorded video and the slider bar to
adjust the volume.
Settings This congures general setting.
Snapshot Take a live snapshot of the recorded video.
Synchronous Playback This syncs four video channels to playback at the same time.
View as 1x1 View one screen at a time.
View as 2x2 View four cameras at a time.
Actual Size The bottom lets you view cameras with the actual size.
Full Screen
View a live video stream of any camera in full scream mode and press Escape to return to the user
interface.
Open Recording Click this button to open an existing recording.
My Surveillance - Playback

D-Link DNS-320L Specifications

Power

power supply	External DC 12 V / 3 A
power saving mode	Auto power recovery
scheduled power off	Supported

Operating Environment

operating temperature	32 to 104 ˚F (0 to 40 ˚C)
storage temperature	-4 to 158 ˚F (-20 to 70 ˚C)
humidity	5% to 90% non-condensing

Ports & Interfaces

ethernet port	1 x 10/100/1000 Gigabit
usb port	1 x USB 2.0
connection to UPS	Supported through USB port

Weight and Dimensions

weight	0.25 lbs
dimensions	3.54” x 5.68” x 7.6”
dimensions (mm)	90 x 144.3 x 193.3 mm
