D-Link DNS-320L User Manual

264D-Link ShareCenter DNS-320L User Manual
Section 4 - Conguration
Click the 1x1 button to enter Single Camera Mode. The live video for the selected camera will expand to cover the
full live viewing area. Click the 2x2 button to return to Split Camera Mode. Click on the camera you wish to view in the
Camera Name and IP Address window.
My Surveillance - Single Camera Live Video Mode

D-Link DNS-320L Specifications

Power

power supply	External DC 12 V / 3 A
power saving mode	Auto power recovery
scheduled power off	Supported

Operating Environment

operating temperature	32 to 104 ˚F (0 to 40 ˚C)
storage temperature	-4 to 158 ˚F (-20 to 70 ˚C)
humidity	5% to 90% non-condensing

Ports & Interfaces

ethernet port	1 x 10/100/1000 Gigabit
usb port	1 x USB 2.0
connection to UPS	Supported through USB port

Weight and Dimensions

weight	0.25 lbs
dimensions	3.54” x 5.68” x 7.6”
dimensions (mm)	90 x 144.3 x 193.3 mm
