D-Link DNS-320L User Manual

273D-Link ShareCenter DNS-320L User Manual
Section 4 - Conguration
My Surveillance - Live Video/Playback Settings
You can access this window from the Live Video window by clicking the Settings
(cog) icon.
Record Display
The Record Display function is only available when accessed from the Playback
screen. The Record Display options allow you to modify what is displayed when
using the Open Recording button on the Playback screen, a calendar month
highlighting dates with recordings or a simple list of folders with recordings.
Play Interval
Use this setting to determine how many minutes one click on the Next Minutes
or Previous Minutes buttons on the control panel advances or rewinds the
video playback.
Capture Image
This allows you to select where to save the snapshots taken using the snapshot
button on the live video screen and the format they are stored in:
Save in Clipboard - Snapshots will automatically be copied to the clipboard.
You should use the Paste function to save the copied image.
Manually save the image le - You will be prompted with a Save File dialog
each time you take a snapshot. You can then choose where to save the captured
image.
Automatically save the image le to - Use the Path button to select a folder
to automatically save each snapshot to.
You can also select the Preferred Image Format from the drop-down menu.

D-Link DNS-320L Specifications

Power

power supply	External DC 12 V / 3 A
power saving mode	Auto power recovery
scheduled power off	Supported

Operating Environment

operating temperature	32 to 104 ˚F (0 to 40 ˚C)
storage temperature	-4 to 158 ˚F (-20 to 70 ˚C)
humidity	5% to 90% non-condensing

Ports & Interfaces

ethernet port	1 x 10/100/1000 Gigabit
usb port	1 x USB 2.0
connection to UPS	Supported through USB port

Weight and Dimensions

weight	0.25 lbs
dimensions	3.54” x 5.68” x 7.6”
dimensions (mm)	90 x 144.3 x 193.3 mm
