39D-Link ShareCenter DNS-320L User Manual
Section 3 - Installation
Under RAID Conguration, Select RAID Type, choose RAID 1. Read the
RAID 1 conguration requirements.
Click Next to continue.
With RAID 1, the drives are mirrored for redundancy. Map Drive to Network
indicates that the NAS has separated the drive into a RAID array. Use the
drop-down menus to select drive letters to map the drives to. For further
information, refer to Mapping a Drive on page 48.
Note: If the size of these two drives are dierent, the excess space on the
larger drive will be formatted as a JBOD Volume.
Click Next to continue.
RAID 1

Table of Contents

Other manuals for D-Link DNS-320L

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DNS-320L and is the answer not in the manual?

D-Link DNS-320L Specifications

Power IconPower
power supplyExternal DC 12 V / 3 A
power saving modeAuto power recovery
scheduled power offSupported
Operating Environment IconOperating Environment
operating temperature32 to 104 ˚F (0 to 40 ˚C)
storage temperature-4 to 158 ˚F (-20 to 70 ˚C)
humidity5% to 90% non-condensing
Ports & Interfaces IconPorts & Interfaces
ethernet port1 x 10/100/1000 Gigabit
usb port1 x USB 2.0
connection to UPSSupported through USB port
Weight and Dimensions IconWeight and Dimensions
weight0.25 lbs
dimensions3.54” x 5.68” x 7.6”
dimensions (mm)90 x 144.3 x 193.3 mm
